NCERT Exemplar Class 12 Physics Chapter 4: Moving Charges and Magntism. NCERT Exemplar Solutions for Class 12 Physics Chapter 4 Moving Charges and Magntism prepare students for their Class 12 exams thoroughly.

Physics problems and solutions for the Class 12 pdf are provided here which are similar to the questions being asked in the previous year’s board.

Contents

**NCERT Exemplar Class 12 Physics Chapter 4: Moving Charges and Magntism**

Class 12: Physics Chapter 4 solutions. Complete Class 12 Physics Chapter 4 Notes.

**Multiple Choice Questions (MCQ I)**

- Two charged particles traverse identical helical paths in a completely opposite sense in a uniform magnetic field B = B0 ˆk
- (a) They have equal z-components of momenta.
- (b) They must have equal charges.
- (c) They necessarily represent a particle-antiparticle pair.
- (d) The charge to mass ratio satisfy : (e/m)
_{1}+ (e/m)_{2}= 0.

- Biot-Savart law indicates that the moving electrons (velocity v) produce a magnetic field B such that
- (a) B ⊥ v.
- (b) B ||v.
- (c) it obeys inverse cube law.
- (d) it is along the line joining the electron and point of observation.

- A current carrying circular loop of radius R is placed in the x-y plane with centre at the origin. Half of the loop with x > 0 is now bent so that it now lies in the y-z plane.
- (a) The magnitude of magnetic moment now diminishes.
- (b) The magnetic moment does not change.
- (c) The magnitude of B at (0.0.z), z >>R increases.
- (d) The magnitude of B at (0.0.z), z >>R is unchanged.

- An electron is projected with uniform velocity along the axis of a current carrying long solenoid. Which of the following is true?
- (a) The electron will be accelerated along the axis.
- (b) The electron path will be circular about the axis.
- (c) The electron will experience a force at 45° to the axis and hence execute a helical path.
- (d) The electron will continue to move with uniform velocity along the axis of the solenoid.

- In a cyclotron, a charged particle
- (a) undergoes acceleration all the time.
- (b) speeds up between the dees because of the magnetic field.
- (c) speeds up in a dee.
- (d) slows down within a dee and speeds up between dees.

- A circular current loop of magnetic moment M is in an arbitrary orientation in an external magnetic field B. The work done to rotate the loop by 30° about an axis perpendicular to its plane is
- (a) MB.
- (b) √3(MB/2)
- (c) (MB/2)
- (d) zero.

**Multiple Choice Questions (MCQ II)**

- The gyro-magnetic ratio of an electron in an H-atom, according to Bohr model, is
- (a) independent of which orbit it is in.
- (b) negative.
- (c) positive.
- (d) increases with the quantum number n.

- Consider a wire carrying a steady current, I placed in a uniform magnetic field B perpendicular to its length. Consider the charges inside the wire. It is known that magnetic forces do no work. This implies that,
- (a) motion of charges inside the conductor is unaffected by B since they do not absorb energy.
- (b) some charges inside the wire move to the surface as a result of B.
- (c) if the wire moves under the influence of B, no work is done by the force.
- (d) if the wire moves under the influence of B, no work is done by the magnetic force on the ions, assumed fixed within the wire.

- Two identical current carrying coaxial loops, carry current I in an opposite sense. A simple amperian loop passes through both of them once. Calling the loop as C,
- A cubical region of space is filled with some uniform electric and magnetic fields. An electron enters the cube across one of its faces with velocity v and a positron enters via opposite face with velocity – v. At this instant,
- (a) the electric forces on both the particles cause identical accelerations.
- (b) the magnetic forces on both the particles cause equal accelerations.
- (c) both particles gain or loose energy at the same rate.
- (d) the motion of the centre of mass (CM) is determined by B alone.

- A charged particle would continue to move with a constant velocity in a region wherein,
- (a) E = 0, B ≠ 0.
- (b) E ≠ 0, B ≠ 0.
- (c) E ≠ 0, B = 0.
- (d) E = 0, B = 0.

**Very Short Answer Type Questions**

- Verify that the cyclotron frequency ω = eB/m has the correct dimensions of [T]
^{–1}. - Show that a force that does no work must be a velocity dependent force.
- The magnetic force depends on v which depends on the inertial frame of reference. Does then the magnetic force differ from inertial frame to frame? Is it reasonable that the net acceleration has a different value in different frames of reference?
- Describe the motion of a charged particle in a cyclotron if the frequency of the radio frequency (rf) field were doubled.
- Two long wires carrying current I1 and I2 are arranged as shown in Fig. 4.1. The one carrying current I1 is along is the x-axis. The other carrying current I2 is along a line parallel to the y-axis given by x = 0 and z = d. Find the force exerted at O2 because of the wire along the x-axis.

**Short Answer Type Questions**

- A current carrying loop consists of 3 identical quarter circles of radius R, lying in the positive quadrants of the x-y, y-z and z-x planes with their centres at the origin, joined together. Find the direction and magnitude of B at the origin.
- A charged particle of charge e and mass m is moving in an electric field E and magnetic field B. Construct dimensionless quantities and quantities of dimension [T ]
^{–1}. - 4.19 An electron enters with a velocity v = v
_{0}i into a cubical region (faces parallel to coordinate planes) in which there are uniform electric and magnetic fields. The orbit of the is found to spiral down inside the cube in plane parallel to the x-y plane. Suggest a configuration of fields E and B that can lead to it. - A multirange voltmeter can be constructed by using a galvanometer circuit as shown in Fig. 4.2. We want to construct a voltmeter that can measure 2V, 20V and 200V using a

galvanometer of resistance 10Ω and that produces maximum deflection for current of 1 mA. Find R_{1}, R_{2}and R_{3}that have to be used. - A long straight wire carrying current of 25A rests on a table as shown in Fig. 4.3. Another wire PQ of length 1m, mass 2.5 g carries the same current but in the opposite direction. The wire PQ is free to slide up and down. To what height will PQ rise?

**Long Answer Type Questions**

- A 100 turn rectangular coil ABCD (in XY plane) is hung from one arm of a balance (Fig. 4.4). A mass 500 g is added to the other arm to balance the weight of the coil. A current 4.9 A passes through the coil and a constant magnetic field of 0.2 T acting inward (in xz plane) is switched on such that only arm CD of length 1 cm lies in the field. How much additional mass ‘m’ must be added to regain the balance?
- A rectangular conducting loop consists of two wires on two opposite sides of length l joined together by rods of length d. The wires are each of the same material but with cross-sections differing by a factor of 2. The thicker wire has a resistance R and the rods are of low resistance, which in turn are connected to a constant voltage source V0. The loop is placed in uniform a magnetic field B at 45° to its plane. Find τ, the torque exerted by the magnetic field on the loop about an axis through the centres of rods.
- An electron and a positron are released from (0, 0, 0) and (0, 0, 1.5R ) respectively, in a uniform magnetic field , each with an equal momentum of magnitude p = e BR. Under what conditions on the direction of momentum will the orbits be nonintersecting circles?
- A uniform conducting wire of length 12a and resistance R is wound up as a current carrying coil in the shape of (i) an equilateral triangle of side a; (ii) a square of sides a and, (iii) a regular hexagon of sides a. The coil is connected to a voltage source V
_{0}. Find the magnetic moment of the coils in each case. - Consider a circular current-carrying loop of radius R in the x-y plane with centre at origin. Consider the line intergral

- (a) Show that ℑ (L) monotonically increases with L.
- (b) Use an appropriate Amperian loop to show that ℑ(∞) = μ
_{0}I, where I is the current in the wire. - (c) Verify directly the above result.
- (d) Suppose we replace the circular coil by a square coil of sides R carrying the same current I. What can you say about ℑ(L ) and ℑ(∞) ?

- A multirange current meter can be constructed by using a galvanometer circuit as shown in Fig. 4.5. We want a current meter that can measure 10mA, 100mA and 1A using a galvanometer of resistance 10Ω and that produces maximum deflection for current of 1mA. Find S
_{1}, S_{2}and S_{3}that have to be used - Five long wires A, B, C, D and E, each carrying current I are arranged to form edges of a pentagonal prism as shown in Fig. 4.6. Each carries current out of the plane of paper.

- (a) What will be magnetic induction at a point on the axis O? Axis is at a distance R from each wire.
- (b) What will be the field if current in one of the wires (say A) is switched off?
- (c) What if current in one of the wire (say) A is reversed?

## Answers to Multiple Choice Questions
