CUCET ME-Mechanical Sample Paper
1. A cyclic heat engine operates between a source temperature of 927 oC and a sink temperature of 27 oC. What will be the maximum efficiency of the heat engine?
- 95%
- 80%
- 75%
- 70%
2. A quasi-static process has main characteristics as it is
- A stationary process
- An infinitely slow process
- A random process
- A spontaneous process
3. All perfect gases change in volume by 1/273th of its original volume at 0°C for every 1°C change in temperature, when the pressure remains constant. This statement is called
- Boyle’s law
- Charles’ law
- Gay-Lussac law
- Joule’s law
4. As the heat rejection temperature decreases in the vapour power cycle below atmospheric pressure,
- The vacuum in the condenser also decreases
- The vacuum in the condenser increases
- It does not produce any vacuum in condenser
- The vacuum in the condenser mybe increases or decrease
5. At ideal condition of vapour power cycle, reversible constant pressure heat rejection is carried out at
- Boiler
- Turbine
- Condenser
- Feed pump
6. Condition under which solid state is converted into liquid state.
- Fusion
- Melting
- Sublimation
- Freezing
7. Critical temperature and critical pressure of steam is
- 20C and 374.15 Bar
- 15 0C and 374.15 bar
- 15 0C and 221 bar
- 25 0C and 321 bar
8. Heat addition takes place at ———– process in case of Rankine cycle
- Isothermal
- Isobaric
- Isentropic
- Isotope
9. Heat supplied rate to steam per unit net power output is defined as
- Steam rate
- Work rate
- Heat rate
- Pulse rate
10. If m1 and m2 are the masses of liquid and vapour respectively in a liquid-vapour mixture, then what is the formula for dryness fraction x?
- x = (m1 + m2) / m1
- x = (m1 + m2) / m2
- x = m1 / (m1 + m2)
- x = m2 / (m1 + m2)
