CUCET ME-EE Sample Paper
1. A synchronous machine has higher capacity for
- leading p.f.
- lagging p.f.
- it does not depend upon the p.f. of the machine
- voltage
2. The positive, negative and zero sequence impedances of a solidly grounded system under steady stale condition always follow the relations
- Z0 < Z1 < Z2
- Z1 < Z2 < Z0
- Z1 > Z2 > Z0
- Z1 = Z2 = Z0
3. When a fault occurs on the system a circuit breaker
- opens automatically
- closes automatically
- opens manually
- closes manually
4. If the length of the arc of circuit breaker increases. its resistance
- decreases
- be extinguished
- remains same
- increases
5. If the dielectric strength of the medium between contacts builds up more rapidly than the restriking voltage, then the arc will
- decrease
- not be extinguished
- increase
- be extinguished
6. The relay with inverse time charac·eristic will operate within
- 5 sec
- 5 to 10 sec
- 10 to 15 sec
- 30 sec
7. The critical clearing time is related to
- steady state stability limit
- transient stability limit
- short-circuit current limit
- insulation limit
8. If the voltage at the two ends of a line are 132 kV and its reactance is 40 ohm, the capacity of the line is
- 435.6MW
- 217.8 MW
- 251.5MW
- 500MW
9. The function of Lightning arrester is
- To limiting the short-circuit fault current
- To provide path to high voltage surge to earth
- To stop arcing
- To reduce arcing
10. Distance relays operation is dependent upon .
- ratio of current to current
- ratio of voltage to current
- ratio of voltage to voltage
- ratio of power to voltage
